Nylon Filter Bags (NMO)
Nylon (NMO) Filter Bags
MejoeFilter Nylon (NMO) filter bags are woven mesh filter bags offering precise filtration with excellent flow rates. Unlike felt bags, NMO mesh provides accurate and consistent micron openings, making them ideal for applications requiring repeatable particle retention. Available in No.1 and No.2 standard sizes with three ring construction options.
Key Features
- Material — Nylon (NMO) woven mesh, precise micron openings for accurate filtration
- Two Standard Sizes — No.1 and No.2 bags to fit standard bag filter housings
- Three Ring Types — PP plastic ring (heat-sealed), galvanized steel ring (sewn), or 304 SS ring (sewn)
- Filtration Precision — 1 to 200 micron ratings available; specify on inquiry
- Compatible — Fits MejoeFilter and standard single-bag and multi-bag filter housings
Specifications
| Specification | No.1 Bag | No.2 Bag |
|---|---|---|
| Diameter | 7" | 7" |
| Length | 17" | 32" |
| Filtration Area | 0.25 m² | 0.5 m² |
| Max. Flow Rate | 20 m³/h | 40 m³/h |
| Max. Temperature | 120°C (248°F) | 120°C (248°F) |
| Micron Rating | 1–200 μm (specify on inquiry) | |
Ring Type Guide
- OR — PP Plastic Ring: Polypropylene ring, heat-sealed bag body
- S — Galvanized Steel Ring: Zinc-plated steel ring, sewn bag body
- A — 304 Stainless Steel Ring: 304 SS ring, sewn bag body, higher temperature and corrosion resistance
Ideal Applications
Food & beverage, ink & coatings, resin filtration, chemical processing, and applications requiring precise particle retention.
Contact us for a custom quote. Specify bag size, ring type, and micron rating.
